Custom Aluminum CNC Machining Parts Anodized CNC Metal Turning Machinery
Parts Processing Services
Advantages of using Aluminum
In addition to its excellent machinability, aluminum demonstrates many characteristics that make
it suitable for use in machining operations, such as:
1. Excellent corrosion and chemical resistance
2. High strength-to-weight ratio
3. Good heat and electrical conductivity
4. Easily machined
5. Reflects heat and light
Product Details
CNC Machining with Aluminum
Aluminum is an excellent material for CNC machining due to its high machinability, ductility,
and favorable strength-to-weight ratio. It offers outstanding thermal and electrical conductivity,
low density, and inherent resistance to corrosion.
| Common Aluminum Materials | |
| No. | Properties |
| Aluminum 6061-T6 | Aluminum 6061 (CNC) is the most popular aluminum alloy. It has good strength-to-weight ratio, excellent machinability and natural corrosion resistance. |
| Aluminum 7075-T6 | Aluminum 7075-T6 (CNC) is an aerospace-grade material with excellent strength-to-weight ratio and strength and hardness comparable to steels. |
| Aluminum 6060 | Alloy 6060 offers good strength, relatively good corrosion resistance and is suitable for decorative anodizing. |
| Aluminum 6082 | Aluminum 6082 (CNC) has very similar composition and properties to 6061, with slightly higher tensile strength. Compliant with British Standards. |
| Aluminum 5083 | Aluminum 5083 (CNC) is a strain hardening aluminum alloy with excellent corrosion resistance. Suitable for marine applications. Can be welded. |
| Aluminum 6063 | Aluminum 6063 has good mechanical properties and can be heat treated. Suitable for aerospace applications. Can be welded. |
| Aluminum 5052 | Aluminum 5052 is a strain hardening aluminum alloy with excellent corrosion resistance. Suitable for marine applications. Can be welded. |
| Aluminum 2024 | Aluminum 2024 is a high-strength alloy with excellent fatigue resistance. Suitable for aerospace applications. |
| Aluminum 7050 | Aluminum 7050 has excellent mechanical properties with good ductility, high strength, toughness and good resistance to fatigue. Suitable for aerospace applications. |
Aluminum Finishing and Post-Processing
Aluminum can also be anodized for additional surface protection and aesthetic finishes.
| Name | Machining Marks |
| Anodizing Type II | Reduced for non-cosmetic, removed on primary surfaces for cosmetic |
| Anodizing Type III | Visible under anodizing |
| Chromate conversion coating | Visible |
| Electroless nickel plating | Reduced but visible |
| As machined | Visible, light surface scratches |
| Smooth machining | Visible, light surface scratches |
| Fine machining | Slightly visible |
| Polishing | Removed on primary surfaces |
| Bead blasting | Removed for non-cosmetic, removed on primary surfaces for cosmetic |
| Brushing | Reduced for non-cosmetic, removed on primary surfaces for cosmetic |
| Powder coating | Removed |
Applications of CNC Aluminum Parts
Aluminum is a popular choice for many metal products and components:
1. Auto Parts 2. Optical Reflectors 3. Aircraft Parts
4. Lighting Fixtures 5. Electronic Enclosures
6. Engine Parts 7. Handles and Knobs
Company Profile
FAQ's
1. What is Anodizing used for?
Anodizing is a process that forms an aluminum oxide layer on the surface of an aluminum alloy,
significantly enhancing its wear resistance due to the hardness of aluminum oxide.
Anodized aluminum finds applications in scenarios where wear resistance is crucial, such as
components constantly in motion and in contact with other materials. Common applications include
coupling bodies, stop flanges, and valves.
Dyeing is another popular application of anodized aluminum. The porous nature of the aluminum
oxide layer created during anodization allows certain dyes to be absorbed, enabling the customization
of colors for aluminum alloys.
This opens up possibilities for dyeing anodized aluminum in products like knobs and body housings.
Furthermore, aluminum oxide, being less conductive than aluminum, can serve as electrical insulation.
This feature finds utility in applications like electric car battery terminals and cable pins, where
electrical isolation is essential.
2. Post-processing and surface finishes for CNC machining
CNC-machined parts as they emerge from the machine often exhibit visible tool marks, a feature that
may not align with your specific part requirements.
Fortunately, there exists a multitude of post-processing techniques aimed at enhancing the surface
appearance and elevating attributes such as wear resistance, corrosion resistance, and chemical
resistance.
Methods like anodizing, bead blasting, and powder coating present viable options for refining the
final presentation of your custom parts, allowing you to achieve the desired surface quality and
performance characteristics.
3. What is the typical delivery time and quotation process?
Delivery time is determined based on the complexity of the parts. For low-complexity parts,
the lead time is typically 2-3 days. As the complexity of the parts increases, the lead time can range
from 2-5 days. High-complexity parts may require a lead time of 5-15 days.
Similarly, the quotation process varies depending on the complexity of your design. Quotes can be
provided in as little as 1 business day, or it may take 3 or more business days for more intricate
designs.
If you have a design that you would like our team to assess and provide a quote for, please don't
hesitate to contact us.
