CNC Milling Service
>
|
|
| Place of Origin | Dongguan, China |
| Brand Name | Yexin |
| Certification | ISO9001:2015 |
| Model Number | SM21 |
Our CNC mills, or CNC milling machines, are capable of producing parts in almost any shape,
using a variety of materials. From soft metals like aluminum to tougher metals like steel, and
even plastics such as acetal, we provide cost-effective milling services. Whether you require a
single part, a batch of prototypes, or a full production order, we have you covered.
Product Details
CNC machining machines exhibit the capability to cut a diverse range of materials, including
aluminum, bronze, copper, ceramics, plywood, various steel alloys, stone, wood, zinc, and other
engineering materials.
This versatility makes CNC machining an ideal choice for generating prototypes in product
development. It enables precise and rapid adjustments until achieving the desired end product.
| Common Materials for CNC Machining | |
| Material | Properties |
| Aluminum | 2024: Good fatigue resistance and strength; excellent toughness at moderate to high strength levels; improved fracture toughness |
| 6061: Excellent machinability, low cost, and versatility | |
| 7075: High strength, hardness, low weight, and heat tolerance | |
| Brass | Versatile and highly attractive copper/zinc alloy with warm yellow color accommodates severe forming/drawing |
| Copper | High ductility and high electrical and thermal conductivity; develops attractive blue-green surface patina over time |
| Stainless Steel | Excellent machinability and outstanding uniformity; good workability and weldability, high ductility and formability |
| Steel Alloy | Mix of chromium, molybdenum, and manganese yields toughness, good torsional and fatigue strength |
| Steel Mild Low Carbon | High machinability and weldability, high stiffness; good mechanical properties, machinability, and weldability at low cost |
| Titanium | Excellent strength to weight ratio, used in aerospace, automotive, and medical industries |
| ABS | Excellent impact resistance, good mechanical properties, susceptible to solvents |
| Nylon | Excellent mechanical properties, high toughness, poor moisture resistance |
| POM | High stiffness, excellent thermal & electrical properties, relatively brittle |
| CNC Milling Tolerances | ||
| Limits for nominal size | Plastics | Metals |
| 0.5mm* to 3mm | ±0.1mm | ±0.05mm |
| Over 3mm to 6mm | ±0.1mm | ±0.05mm |
| Over 6mm to 30mm | ±0.2mm | ±0.10mm |
| Over 30mm to 120mm | ±0.3mm | ±0.15mm |
| Over 120mm to 400mm | ±0.5mm | ±0.20mm |
| Over 400mm to 1000mm | ±0.8mm | ±0.30mm |
| Over 1000mm to 2000mm | ±1.2mm | ±0.50mm |
| Over 2000mm to 4000mm | ±2.0mm | |
|
*Please clearly indicate tolerances for nominal sizes below 0.5mm on your technical drawing. |
||
CNC Machining Applications
CNC machining stands out as one of the most accurate manufacturing techniques, making it an
ideal choice for the creation of complex designs. Its precision and versatility enable the production
of a wide range of products, including:
1. Aerospace Components:
CNC machining is extensively used in the aerospace industry to manufacture intricate and precise
components for aircraft and spacecraft.
2. Furniture:
In the furniture industry, CNC machining allows for the creation of intricate and precisely crafted
furniture pieces, enhancing design possibilities.
3. Medical Components:
The medical industry benefits from the accuracy of CNC machining in the production of complex
components for medical devices and equipment.
Company Profile
FAQ's
1. What are the minimum and maximum dimensions you can machine?
Our CNC machining services encompass CNC milling (3-axis, 3+2-axis, and 5-axis)
as well as turning. For 3/3+2-axis CNC milling, we can machine parts with dimensions up to
2000 x 1500 x 200 mm (78.7 x 59.0 x 7.8 in.).
In the case of 5-axis milling, the maximum part size is 650 x 650 x 300 mm (25.5 x 25.5 x 11.8 in.).
For CNC turning, we can handle parts with a maximum diameter of 431 mm (17 in.)
and a length of 990 mm (39 in.). Recommended minimum part dimensions are approximately
10 x 10 x 10 mm (0.39 x 0.39 x 0.39 in.), and feature dimensions should not go below 0.5 mm.
It's important to note that our platform has a limitation of a maximum part size of 1000 mm (39 in.).
If your project requires dimensions beyond this limit, please contact our sales team to discuss your
specific needs.
2. How much does CNC machining cost?
The cost of CNC machining is influenced by factors such as complexity, quantity, and lead time.
For an accurate assessment, the best approach is to submit a 3D CAD model, allowing us to provide
an interactive quote along with design for manufacturability (DFM) feedback.
Notably, our use of proprietary software and automated fixturing processes eliminates upfront
non-recurring engineering (NRE) costs. This streamlined approach makes purchasing quantities
as low as 1 to 200 parts cost-effective. While prices may be comparable to or slightly higher than
3D printing, CNC machining offers superior material properties and surface finishes.
3. What are standard machining tolerances?
The standard machining tolerance is ± 0.005" or 0.13mm, defining the acceptable range for a
dimension. If a CNC machining tool has a tolerance of ± 0.01 mm, it implies a deviation of 0.01 mm
in each cut. When accompanied by a drawing, our CNC machining service can achieve CNC parts
with tolerances as low as ± 0.0002 in.
In the absence of a drawing, all CNC parts are produced following our ISO 2768 medium standard.
Additionally, we have the capability to machine to tighter tolerances, such as ±0.025mm or ±0.001",
when an engineering drawing specifies critical features.
