CNC Milling Service
>
|
|
| Place of Origin | Dongguan, China |
| Brand Name | Yexin |
| Certification | ISO9001:2015 |
| Model Number | SM14 |
To maximize efficiency and minimize costs in CNC milling, consider the following strategies,
primarily centered around designing "Simple" and "Standard" parts:
1. Simplicity is Key: Whenever possible, design parts with straightforward features that can be
produced using standard-sized tooling. This approach tends to yield more successful results.
2. Minimize Complexity: While complexity is essential when required, it can lead to longer lead
times and increased costs. For instance, a part with a single complex feature may not pose
significant challenges when made from aluminum, but it can become daunting when using plastic,
especially in mass production.
In essence, prioritize simplicity and standardization in your design. While there may be occasions
where complexity or specialized materials are necessary, these factors often result in more intensive
and costly CNC milling processes.
Product Details
CNC machining machines possess the versatility to cut through an extensive array of materials,
encompassing aluminum, bronze, copper, ceramics, plywood, diverse steel types, stone, wood,
zinc, and various engineering materials.
This broad range of capabilities positions CNC machining as an optimal solution for prototype
creation in product development. It facilitates the ability to make accurate and swift adjustments
until achieving satisfaction with the final product.
| Common Materials for CNC Machining | |
| Material | Properties |
| Aluminum | 2024: Good fatigue resistance and strength; excellent toughness at moderate to high strength levels; improved fracture toughness |
| 6061: Excellent machinability, low cost, and versatility | |
| 7075: High strength, hardness, low weight, and heat tolerance | |
| Brass | Versatile and highly attractive copper/zinc alloy with warm yellow color accommodates severe forming/drawing |
| Copper | High ductility and high electrical and thermal conductivity; develops attractive blue-green surface patina over time |
| Stainless Steel | Excellent machinability and outstanding uniformity; good workability and weldability, high ductility and formability |
| Steel Alloy | Mix of chromium, molybdenum, and manganese yields toughness, good torsional and fatigue strength |
| Steel Mild Low Carbon | High machinability and weldability, high stiffness; good mechanical properties, machinability, and weldability at low cost |
| Titanium | Excellent strength to weight ratio, used in aerospace, automotive, and medical industries |
| ABS | Excellent impact resistance, good mechanical properties, susceptible to solvents |
| Nylon | Excellent mechanical properties, high toughness, poor moisture resistance |
| POM | High stiffness, excellent thermal & electrical properties, relatively brittle |
| CNC Milling Tolerances | ||
| Limits for nominal size | Plastics | Metals |
| 0.5mm* to 3mm | ±0.1mm | ±0.05mm |
| Over 3mm to 6mm | ±0.1mm | ±0.05mm |
| Over 6mm to 30mm | ±0.2mm | ±0.10mm |
| Over 30mm to 120mm | ±0.3mm | ±0.15mm |
| Over 120mm to 400mm | ±0.5mm | ±0.20mm |
| Over 400mm to 1000mm | ±0.8mm | ±0.30mm |
| Over 1000mm to 2000mm | ±1.2mm | ±0.50mm |
| Over 2000mm to 4000mm | ±2.0mm | |
|
*Please clearly indicate tolerances for nominal sizes below 0.5mm on your technical drawing. |
||
CNC Machining Applications
CNC milling machines let operators create complex designs with very tight tolerances.
As a result, it is one of the most accurate manufacturing techniques to date.
Here’s a look at the products you can create:
1. Aerospace components such as landing gear components, fuselage structures
2. Components for the automotive industry such as control panels, axles, car molds
3. Consumer electronics components such as enclosures
4. Medical components such as surgical instruments, orthotics
5. Oil and gas machine parts such as valves, rods, pins
6. Prototyping and modeling
7. Sculptures
8. Furniture
9. Woodworking
Company Profile
FAQ's
1. What industries do you typically work in? Who are your typical customers?
We have an extensive presence across various industries, working with heavy equipment
manufacturers, general commercial businesses, and companies in industrial, transportation,
medical, and consumer sectors, among others.
Our clientele spans the United States, Europe, and worldwide. Despite the diversity in industries,
our customers share a common requirement for high-quality parts machined to specifications,
delivered on time, and within budget.
2. Can you ensure my designed component dimensions and tolerances are suitable for
production?
Our team of seasoned professionals is well-equipped to offer "Design for Engineering" (DFM)
support, assessing the feasibility of your designed component dimensions and tolerances for
production.
Recognizing the importance of swift responses during the ideation and testing phase, we ensure a
fast turnaround on quotes. For a comprehensive overview of the entire order progress, you can refer
to our production process page.
3. What is your typical lead time? Can my parts be produced on a rush basis?
Our typical lead time, encompassing quoting, manufacturing, and shipping, for screw machine
products is around one week. Rest assured, our on-time delivery rate exceeds 99%. Should you
require an expedited production timeframe, we can explore the possibility based on factors like
tooling, gauges, and material availability in the marketplace. Feel free to inquire!
